Quick start

Run the server

Usage: ./rpcserver [-p port] [-o (stdout|syslog|file:filename)]
-h  show this help message
-o  output. can be all of: stdout, syslog and file:filename. can be passed multiple times

Example:
./rpcserver -p 5910 -o syslog -o stdout -o file:/tmp/log.txt

Connect the client

Connect to a running server (HOSTNAME is optional — omit it to start without a connection and connect later from the console):

rpcclient [HOSTNAME]
# or: python3 -m rpcclient [HOSTNAME]

To control the local machine (no remote server needed), use:

rpclocal

Full usage:

Usage: rpcclient [OPTIONS] [HOSTNAME]

  Start the console. If HOSTNAME is provided, connect immediately. Otherwise,
  start without a connection. You can connect later from the console.

Options:
  -p, --port INTEGER        TCP port to connect to
  -r, --rebind-symbols      reload all symbols upon connection
  -l, --load-all-libraries  load all libraries
  -f, --startup-files PATH  File(s) (python) to run on session start. Repeatable.
  --help                    Show this message and exit.

Connecting to a jailbroken iOS device

You'll need a TCP tunnel to the device first, e.g. with pymobiledevice3:

python3 -m pymobiledevice3 usbmux forward 5910 5910 -vvv

The console: mgr, console, p

You land in an IPython shell with three globals:

  • mgr — client manager: mgr.create(hostname="127.0.0.1", port=5910), mgr.get(pid), mgr.remove(pid), mgr.clients, mgr.clear()
  • console — context controller: console.switch(pid), or console.switch() to pick interactively
  • p — the active client; auto-updated when you switch context (p.info(), p.pid, p.fs.listdir("."), p.spawn([...]))

F1 shows help, F2 shows active contexts, F3 switches to the previous context, F4 toggles auto-switch on creation.

[Rpc-client]: mgr.create(hostname="127.0.0.1")
Auto-switched to new client PID: 79669
[osx| (79669) rpcserver_macosx]: <MacosClient: 79669 | rpcserver_macosx>

Try it

[osx| (78479) rpcserver_macosx]: p.spawn(['sleep', '1'])
SpawnResult(error=0, pid=25047, stdout=<_io.TextIOWrapper ...>)

[osx| (78479) rpcserver_macosx]: p.fs.listdir('.')
['common.c', 'Makefile', 'rpcserver.c', ...]

[osx| (78479) rpcserver_macosx]: p.processes.get_by_pid(p.pid).fds
[FileFd(fd=0, path='/dev/ttys000'), ...]

Explore the rest through p. Next: Calling native functions.
